Open Type Thin Material Straightener / Leveler Coil Feeder Machine High Accuracy

open type thin material straightener/ leveler-coil feeding line

Model:
JM series

Straightening Details

1, the machine uses the lifting type leveling roller group structure, 45 degree oblique lift, can quickly and thoroughly clean the roller and convenient mechanical inspection, to ensure leveling accuracy, leveling for 0.3 ~ 1.5mm, stainless steel, copper, iron, aluminum and other sheet materials, can achieve perfect leveling effect the.
2 , the leveling roller adopts independent transmission, the upper and the lower parts are assembled with an auxiliary roller, and the bending direction of the material can be adjusted according to the requirement.
3, the drum is adjusted by the original score type adjustment mode instead of the traditional dial type regulating mode, without additional correction, debugging is more simple and accurate, longer service life.
4, leveling roller material adopts bearing steel, by heat treatment quenching HRC, 60 degrees after plating hard chromium, then grinding, high hardness, wear resistance, long life.
5. The bearings on both sides of the roller are free of oil and without lubrication. They are wearable and free from oil or dirt.
6, frequency control speed, material operation process is not easy to shake deformation, to ensure high precision leveling needs.
7, the inlet and outlet are equipped with inlet and outlet wheel assembly, convenient feeding and discharging.
8, leveling machine inside lever roller, blank width 300mm above the other with the leveling auxiliary wheel to prevent leveling roller due to excessive pressure and bending deformation, strengthen the leveling effect of leveling roller and the life and improve the plate surface flatness requirement.
