10 Ton Auto Workshop Equipment Flat Rail Transfer Cart Or Motorized Trolley

10 Ton Auto Workshop Equipment Flat Rail Transfer Cart Or Motorized Trolley
10 Ton Auto Workshop Equipment Flat Rail Transfer Cart Or Motorized Trolley

Large Image :  10 Ton Auto Workshop Equipment Flat Rail Transfer Cart Or Motorized Trolley

Product Details:
Place of Origin: China-Wuxi Jinqiu Machinery Co.,ltd
Brand Name: Jinqiu
Certification: CE and CQC
Model Number: KPX6
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: USD or RMB
Packaging Details: metal steel frame
Delivery Time: 55-60 days
Payment Terms: L/C, T/T
Supply Ability: 150 pcs per month
Detailed Product Description
Material: Q235 Or Q345 Mild Steel Loading Capacity: 10 Ton
Control Mode: Push Button Control, Wireless Remold Power: Battery
High Light:

rail transfer trolley

,

rail transfer cart

,

10 ton flat rail transfer cart

10 Ton Auto Workshop Equipment Flat Rail Transfer Cart Or Motorized Trolley



Application:

The transfer machine is designed for transporting heavy cargoes or equipment from one bay to another in factory. It can be used indoor or outdoor. The fields include metallurgy, foundry, new factory construction and shipbuilding and so on. With different styles and standard capacities up to 300 tons, we have the solution you need and each style can be designed for your specific application.

Our transfer cart model main contains KPD, KPJ,and KPX, If you are unsure as to what type of transfer cart will best serve your needs. Spending a few minutes now discussing the needs of your application could save you dollars in the future.



Quick Details:

  • The transfer machine is suitable for various industries, steel mill, transfer steel products such as steel structure, steel pipe, steel billets, steel ladle and coil, etc
  • For horizontal load transfers of a wide range of material, hycrane has the heavy duty, high quality Transfer Cart solution you need.
  • Transfer carts are used: to carry loads along assembly lines; transfer material from one work station to the next; store and transport an entire shift worth of production. They can even be used as a stable yet moveable machine base.
  • It's necessary equipment for lifting goods,raising labor efficiency,improving working conditions.

10 Ton Auto Workshop Equipment Flat Rail Transfer Cart Or Motorized Trolley 0

Technical Parameters:
Mode: KPX10

1. Model KPX 10
2. Rated Load (T) 10
3. Table Size(L×B×H)(in mm) 3600×2000×550
4. Working Speed(m/min) 30
5. Bottom Tolerance(mm) 50
6. Diameter of wheel(mm) 400
7.

Broadside distance inside of rail C(mm)

(Drawing enclosed)

1435

(+0/-3mm)

8. Distance of Axis A(mm) 2000
9. Motor Model/Power(kw)

XQ-1.5

10. Battery Model Capacity/Voltage Complete with Battery Bank

3D 190

190 Ah/36V

11. Weight(T) 3
12. Recommended steel rail model Drawing enclosed
13. Quantity of wheel 4/3.3T



10 Ton Auto Workshop Equipment Flat Rail Transfer Cart Or Motorized Trolley 1

 Packageing & Delivery
Packaging details:Plywood case
Delivery detail: 55-60 days



Why Choose Us?
Jinqiu is a famouse and long history brand in China, after more than 47 years research, our design from technology, structure and precision are very mature, many other factories just copy our outlooking, but the process is not advantages. And we also obtained the CE and more strict standard certification. Our machines distribute worldwide about 20 countries which penetrate into more metal plate industries.

Questions:
1. Are you a trading company or factory?
  --- We are factory occupying more than 62,000 m2,  with excellent and professional technical team, 25 R&D personnel, professional after-sales team, and around 300 workers producing more than 1000sets machines each year.

2. Does your company supply and build the machines to suit customer's needs and specifications?
  --- Yes, we can custom-made the machine according to your requirements.

3. What is your advantages over your competitors' machine?
  --- Our machines can be equipped with high configuration, and main components are from famous brands. We have strict quality control system, process technology system, technology innovate system.

4. Does the machine come with a guarantee?
  --- We offer one year of warranty, during this time, if any parts broken, we will send a new one to customer free of charge, and we will also supply on-line the technical guidance for ever free.

5. Can I go to visit your factory?
  --- Welcome to visit our factory to know our processing and technology power. And you will see different sample machine at our workshop.

6. How to get quicker quotation?
  --- When you send us inquiry, please offer your requirement information:
• What kind of metal plate and the thickness?
• How about your configuration requirement?
• You also send us your bend products image, our engineer can design for you.
These information is helpful for us to choose suitable equipment solution and price quickly.
